Double Indemnity choice for modular houses, Vila buildings and Camp buildings etc.
Features
* 304 stainless steel mesh screen door
* Pre-hung design to save labour cost
* Electrostatic powder coating finish guarantee the quality
* EPS/PU Foam infilling make door excellent in thermal and acoustic performance
* Timber blocks are fitted inside of door leaf to meet lock, hinges and door closer
* Lock hole prepared
Technical Specifications
*The door assembly is ready for installation into an existing opening.
Door Leaf Size:
Single Door Size (mm) – 2040H x 820/870/920W x 40T
*Customized sizes are available.
Opening Direction:
Reversible & wheelchair design for both right hand & left hand & disabled choice.
Door Core:
Polystyrene panel/PU foam/High quality honeycomb paper/Rock wool
Steel sheet:
Galvanized steel sheet materials with high-quality powder coating finish
Door Frame:
*. Frame made of 1.5mm thick galvanized steel sheet with fixing holes for prefabricated building
*. Frame consists of two parts (internal & external frame) to adjust 100-150wall thickness.
Weather sealing:
Sealing all-round the external frame with EPDM flexible seal to keep dust and rain;
Security screen with 304/316 stainless mesh is optional for high quality requirement.
Hardware:
*304 type stainless steel hinges, can be powder coated same as door colour
*Lock hole prepared for spherical lock/lever handlel ock with 60-70mm backset
*Heavy duty commercial grade overhead door closers are optional.
*Panic exist device is optional.
Package
*Economic and popular pallet package for end customers-8sets per pallet, 10 pallets for 20ft container.
