Applications
Popular choice for warehouse, escape passage, apartment buildings etc.
Features
* Can be Pre-hung design to save labour cost; Can be Integrated frame to meet concrete wall installation.
* Electrostatic powder coating finish guarantee the quality
* PU Foam/Rock wool infilling make door excellent in thermal,acoustic and fireproof performance
* Timber blocks are fitted inside of door leaf to meet lock, hinges,door closer and panic bar
* Security lock or Passage lock are optional
Technical Specifications
*The door assembly is ready for installation into an existing opening.
Door Leaf Size:
Double Door Size (mm) – 2040H x (820+820)W x 40T; 2000H x (800+800)W x 40T
*Customized sizes are popular.
Opening Direction:
Outward/Inward choice.
Door Core:
PU foam infilling/High quality honeycomb paper/Rock wool
Steel sheet:
Galvanized steel sheet materials with high-quality powdercoating finish
Door Frame:
1. Split Frame made of 1.5mm thick galvanized steel sheet with fixing holes for metal warehouse building
2. Integrated Frame is invisible installation with anti-thief bolt .
Weather sealing:
Sealing all-round the external frame with EPDM flexible seal to keep dust and rain
Hardware:
*304 type stainless steel hinges, can be powder coated same as door colour
*Lock hole prepared for spherical lock/lever handlel ock with 70mm backset
*Heavy duty commercial grade overhead door closers are optional.
*Panic exist device is optional.
* Anti-thief bolts on top & bottom of the door leaf which has rebated edge
Door Sill:
1.Disable compliant sill is optional
2.Temporary sill is optional
Package
*Economic and popular pallet package for end customers-15sets per pallet, 5 pallets for 20ft container.
*Luxury Cardboard package for distributors-10sets per pallet, 6 pallets for 20ft container.
